9 Technical Data
9.2 MF1000-1
Standard IEC 61000-4-8
IEC 61000-4-9
IEC 61000-4-10
Coil Size 1 m x 1 m
Coil Factor 0.87
AC Magnetic field
9
Range 1 0.8 A/m - 5.0 A/m
continuous
Range 2 5.0 A/m - 40 A/m
continuous
Range 3 40 A/m - 160 A/m
continuous
CWG Magnetic field
10
8/20 us 93 A/m - 1855 A/m
DOW Magnetic field
11
100 kHz 5 A/m - 220 A/m
1 MHz 2.5 A/m - 110 A/m
Dimensions 120 cm x 100 cm x 10.5 cm
Weight 6 kg
9.3 MF1000-2
Standard IEC 61000-4-8
IEC 61000-4-9
IEC 61000-4-10
Coil Size 1 m x 2.6 m
Coil Factor 0.66
AC Magnetic field
12
Range 1 0.5 A/m - 3.5 A/m
continuous
Range 2 3.5 A/m - 28 A/m
continuous
Range 3 28 A/m - 110 A/m
continuous
CWG Magnetic field
13
8/20 us 67 A/m - 1345 A/m
DOW Magnetic field
14
100 kHz 5 A/m - 160 A/m
1 MHz 2.5 A/m - 60 A/m
Dimensions 120 cm x 260 cm x 10.5 cm
Weight 24 kg
9
Effective range depends on generator. See technical specification of IMU-Generators.
10
Effective range depends on generator. See technical specification of IMU-Generators.
11
Effective range depends on generator. See technical specification of DOW-Generators.
12
Effective range depends on generator. See technical specification of IMU-Generators.
13
Effective range depends on generator. See technical specification of IMU-Generators.
14
Effective range depends on generator. See technical specification of DOW-Generators.
