9 Technical Data
9.10 VERI50 EFT
Impedance 50 Ω±2 %
Ratio
50 ΩDSO Input 1:1000 ±2 %
1 MΩDSO Input 1:500
Tolerance of Insertion Loss
up to 100MHz ±0.5 dB
up to 400MHz ±3 dB
Max. Level 7100 V EFT- or DOW-Impulse
Max. average Spikes/s 350 @7100 V
Dimension 15.5 cm x 2.5 cm x 2.5 cm
Weight 0.1 kg
9.11 CN-EFT1000
Standard IEC 61000-4-4
IEC 61000-4-18:2019
Insulation
EFT 5 ns / 50 ns 8 kV
DOW 3 MHz / 10 MHz / 30 MHz 5 kV
CWG 1.2 us / 50 us 5 kV
Usable cable diameter up to 70 mm
Coupling capacitance typically 100 pF - 1000 pF
EFT Calibration into 50 Ω
Level 1000 V ±20 %
Rise time 5 ns ±1.5 ns
Duration 50 ns ±15 ns
DOW Calibration into 50 Ω
Level 1000 V ±20 %
Frequency 3 MHz ±20 %
10 MHz ±20 %
30 MHz ±20 %
Dimensions 114 cm x 15 cm x 10 cm
Weight 4 kg
