9 Technical Data
9.1.5 Insulation 0.5 Joule
Standard 61180-1/2
60060-1
62052-11
60255-27
60834-1/2
EN 50470-1
Open Circuit
Level 500V +0 %/-10 %
1000V +0 %/-10 %
1500V +0 %/-10 %
2000V +0 %/-10 %
2500V +0 %/-10 %
3000V +0 %/-10 %
4000V +0 %/-10 %
5000V +0 %/-10 %
6000V +0 %/-10 %
8000V +0 %/-10 %
Rise time 1.2 µs ±30 %
Duration 50 µs ±20 %
Source Energy 0.5 J ±10 %
Impedance 500 Ω±10 %
Polarity positive
negative
alternating
Repetition 1 s - 655 s
Trigger Mode automatic
manual
external
Measurement
Internal Voltage Peak ±5 %
CH1 Voltage Monitor 1:4000 into 50 Ω±5 %
Coupling Device Direct Output
