9 Technical Data
9.1.4 DOW Slow Magnetic Field
Standard IEC 61000-4-10:2016
Frequency 100 kHz ±10 %
1 MHz ±10 %
Test Time 1 s to 65535 s
Burst Repetition 100 ms to 200 s ±10 %
Burst Duration 1 ms to 20 s ±10 %
Pulse Spacing
100 kHz 20 ms to 400 ms ±10 %
1 MHz 2 ms to 400 ms ±10 %
Decaying
Peak5 to Peak1 >50 %
Peak10 to Peak1 <50 %
Polarity positive
negative
alternating
Trigger Mode automatic
manual
external
Coupling Device MF1000-1
MF1000-2
MF1000-1
Level
100 kHz 5 A/m - 220 A/m ±20 %
1 MHz 2.5 A/m - 110 A/m ±20 %
max. average Spikes/s
7
100 kHz 846e3/[Level in A/m]
2
1 MHz 2.22e6/[Level in A/m]
2
MF1000-2
Level
100 kHz 5 A/m - 160 A/m ±20 %
1 MHz 2.5 A/m - 60 A/m ±20 %
max. average Spikes/s
8
100 kHz 400e3/[Level in A/m]
2
and max. 50
1 MHz 656e6/[Level in A/m]
2
and max. 500
7
The maximum number of spikes per second can be limited due to the minimum allowed pulse spacing. The maximum
number of spikes per second is derated depending on the level.
8
The maximum number of spikes per second can be limited due to the minimum allowed pulse spacing. The maximum
number of spikes per second is derated depending on the level.
