Emerson Branson 2000X - Figure 2.1 Frontal View of the 2000 X Micro Actuator Power Supply Manual Set; Table 2.1 Frontal View of the 2000 X Micro Actuator and Interface Box

100-412-182 REV. 06 17
Figure 2.1 Frontal view of the 2000X Micro Actuator Power Supply Manual Set
Table 2.1 Frontal View of the 2000X Micro Actuator and Interface Box
Item Description
1 Power Indicator Light
2 Power Indicator Light
3 System Pressure On Indicator
4 Air Pressure Adjust
5 Down Speed Control
6 Interface Box
7 Mechanical Stop Adjust
8 Actuator
8
2
3
1
4
5
7
6
