46 100-412-182 REV. 06
5.4 Installation Requirements
5.4.1 Location
The Actuator may be installed in a variety of positions. It is usually mounted directly on
automated or semi-automated equipment. It may be manually or automatically loaded
and unloaded.
The interface box may be located up to 3 feet away from the Actuator. The power supply
can be located up to 15 feet from the Actuator. The power supply must be accessible for
user parameter changes and settings, and must be placed in an horizontal orientation.
The power supply should be positioned so it does not draw in dust, dirt or material via its
rear fans. Refer to the illustrations on the pages that follow for a dimensional drawing of
each component. All dimensions are approximate and may vary between models.
Figure 5.2 Power Supply Dimensional Drawing
Figure 5.3 2000X Micro Actuator and Interface Box Dimensional Drawing
5.4.2 Environmental Specification
NOTICE
The Interface Box on the 2000X Micro Actuator can be located at a
maximum of 3 feet from the Actuator.
Table 5.4 Environmental Specifications
Environmental Concern Acceptable Range
Humidity Maximum 95%, non-condensing
Operating Altitude Up to 6560 ft (2000 m)
Ambient Operating Temperature +5º C to +50º C (41º F to 122º F)
Storage / Shipping Temperature
-25º C to +55º C (-13º F to + 131º F); Up
to +70º C (+158º F) for 24 hours
