100-412-182 REV. 06 59
EMER STOP is an emergency stop switch, normally closed.
5.5.7 Input Power Plug
If you must add or change the input power plug, use the following color code for the
conductors found in the international harmonized line cord. Add the plug that is
appropriate for your input power receptacle.
Figure 5.11 Line Cord Color Code
NOTICE
Refer to the Branson Automation Guide (EDP 100-214-273) for
additional information about selection and use of Input and Output
features.
CAUTION General Warning
The Power Supply can be permanently damaged if it is connected to
the incorrect line voltage, or if the wiring connection is mis-wired. It
also presents a safety hazard if mis-wired. Use of the correct lug or
connector helps prevent incorrect connections.
WARNING General Warning
Unplug the Power Supply (if previously connected) and wait at least
two (2) minutes before opening the Power Supply case. Hazardous
Voltages exist and are stored in the system.
BLUE = Neutral 120v operation, line for 220v
BROWN = Line
GREEN/YELLOW TRACE = Earth Ground
Line Cord Jacket
To Next Page
