6.3 Operating the Actuator
For detailed information about 2000X Micro Actuator controls, see 2.4 Controls and
Indicators.
If you do not obtain optimal results initially, based on the quality of the weld obtained and
the loading meter reading, you can alter settings to achieve satisfactory results. Change
one setting at a time until a weld is produced in minimum time with maximum strength.
Table 6.2 To Operate the 2000X Micro Actuator
Step Action
1
If your application has been analyzed in the Branson Applications Laboratory,
consult the Branson Lab Report for appropriate settings or check the 2000X
distance Power Supply manual.
2
Properly adjust the mechanical stop so that the horn does not make contact
with your fixture. See 6.2.6 Mechanical Stop for more information.
3
Verify that the Emergency Stop signal source is not in the Emergency Stop
mode.
4
With a part in place, supply and hold the start signal, or depress and hold
both start switches simultaneously.
5 The horn advances and contracts the part.
6 Force develops between the horn and the part, activating the load cell.
7
Ultrasonic vibrations are activated. The power bag graph on the Power Supply
indicates loading (usually in the 25% to 100% range). The start signal / start
switches can now be released.
8
Ultrasonics stop and the horn continues to clamp the part for the hold time
you selected.
9
After the completion of the hold cycle, the horn retracts automatically and you
can remove the part from the fixture.
10
Weld a few parts using the initial parameters and check for the desired
properties.
