100-412-182 REV. 06 81
7.3 Parts Lists
The following tables lists the available Accessories (Table 7.2 Accessories List for 2000X
Micro Actuator) and Parts (Table 7.3 Spare Parts List for the 2000X Micro Actuator) for the
2000X Micro Actuator:
7.3.1 Accessories
7.3.2 Spare Parts
Table 7.2 Accessories List for 2000X Micro Actuator
Description EDP #
2000X Micro Actuator with 40 mm cylinder 101-134-290E
Converter 4TJ 101-135-041R
Boosters - 40 kHz (Same as XL: 8 mm)
Black (Ti), Ratio 1:2.5 101-149-084
Silver (Ti), Ratio 1:2.0 101-149-083
Gold (Ti), Ratio 1:1.5 101-149-086
Green (Ti), Ratio 1:1 101-149-085
Black (Al), Ratio 1:2.5 101-149-082
Silver (Al), Ratio 1:2.0 101-149-081R
Gold (Al), Ratio 1:1.5 101-149-080
Green (Al), Ratio 1:1 101-149-079
Purple (Al), Ratio 1:0.6 101-149-087
Solid Mount Boosters - 40 kHz (Same as XL: 8 mm)
Black (Ti), Ratio 1:2.5 109-041-174
Silver (Ti), Ratio 1:2.0 109-041-175
Gold (Ti), Ratio 1:1.5 109-041-176
Green (Ti), Ratio 1:1.0 109-041-177
Purple (Ti), Ratio 1:0.6 109-041-178
Table 7.3 Spare Parts List for the 2000X Micro Actuator
Description EDP #
Micro Linear Encoder Assembly BU-1036907
RF Harness Assembly 100-246-1382
