38 100-412-182 REV. 06
4.1 Technical Specifications
4.1.1 Requirement Specifications
The 2000X Micro Actuator requires compressed air. The factory air source must be “clean
(5 micron) and dry”, that is, does not include moisture or lubricants. The Actuator requires
70 psi minimum pressure for operation and cooling, and can require up to 80 psig
maximum, depending on the application. The following table lists environmental
specifications for the ultrasonic welder.
All electrical input power connections are to the Power Supply.
4.1.2 Performance Specifications
The following table details some of the performance specifications associated with the
2000X Micro Actuator.
Table 4.1 Environmental Specifications
Environmental Concern Acceptable Range
Humidity Maximum 95%, non-condensing
Operating Altitude Up to 6560 ft (2000 m)
Ambient Temperature +5º C to +50º C (+41º F to +122º F).
Storage/Shipping Temperature
-25º C/-13º F to +55º C/+131º F
(+70º C/+158º F for 24 hours).
Table 4.2 2000X Micro Actuator Performance Specifications
Performance Specifications
Maximum clamping force on part
(at 80 psig / 550 kPa)
115 lbs / 511 N
Dynamic triggering range 5-115 lbs / 22.2-511 N
Dynamic follow-through 40 lbs to max clamp force
Maximum traverse speed
7 inch / 177.8 mm per sec. max at 1.75” /
44.4 mm stroke, 80 psi
Minimum stroke 0.25 inch / 6.3 mm
Maximum stroke 1.75 inch / 44.4 mm
