100-412-182 REV. 06 45
5.3 Take Inventory of Small Parts
Small Parts included (=x).
5.3.1 Cables
Two cables connect the actuator and interface box: the encoder cable, and the control
cable. The power supply provides control signals to the interface box via the actuator
interface cable, and supplies ultrasonic energy to the actuator through the RF cable. If the
system is to be automated, you may also need a J911 start cable and a user I/O cable.
Check your invoice for cable types and cable lengths.
Table 5.2 Power Supply and/or Actuator Assemblies
Part or Kit
2000X Power Supply
40 kHz
Actuator
40 kHz Spanners (2) x
Silicone Grease x
T-Handle Wrench, Micro
Actuator M4
x
Actuator Mtg. Bolts (2) x
Actuator Mtg. Washers x
5/64 Allen Wrench x
Table 5.3 List of Cables
EDP Description
100-240-365 Control Cable
100-240-364 Encoder Cable
101-241-203 Actuator Interface, 8’ (J925S)
101-241-204 Actuator Interface, 15’ (J925S)
101-241-207 Alarm I/O, 8’ (J957S)
101-241-208 Alarm I/O, 15’ (J957S)
101-240-020 Start Cable (J911) 8’ (req PLA)
101-240-015 Start Cable (J911) 15’ (req PLA)
101-241-248 Terminal - 8’
101-241-249 Terminal - 15’
101-240-179 RF, 8’ CE SHV (J934C)
101-240-181 RF, 15’ CE SHV (J934C)
100-246-630 Ground Detect Cable
100-143-043R Printer, 6’
