100-412-182 REV. 06 51
5.4.5.2 Pneumatic Connections to Actuator
Pneumatic connections to the 2000XMicro actuator are identified as cylinder top, cylinder
bottom, pressure indicator and converter cooling (at the front of the Actuator). The
interface box houses the main air inlet and exhaust, along with the 3 output air
connections to the Actuator.
You must provide an air filter assembly to the remote box which will support at least 80
psig and remove particulate matter of 5 microns or larger.
WARNING General Warning
Filtered cooling air (80 SCHF) must be provided to the Actuator
through the air inlet located at the front of the Actuator. Failure to
connect cooling air may void product warranty. Consult with a
Branson representative if you have any questions.
