70 100-412-182 REV. 06
6.2.3 Downspeed Control
The Downspeed Control regulates the horn velocity. If the Downspeed control is closed,
the actuator will not extend.
6.2.4 Actuator Alignment and Height (Horn travel)
The horn carriage will travel up and down on the Actuator’s slides. The distance between
the fixture and horn should allow easy and ready access and removal of your parts.
Consistent weld results are best obtained when the horn travel is more than 1/4 inch,
because a short distance weld can be affected by other components of the welding system
and the pressure build-up on the parts.
6.2.5 USB
The two USB ports available on the 2000X power supply are USB 2.0 compliant, allowing
complete plug and play, and hot attach/detach for up to 127 external devices. USB 2.0 is
fully backward compatible with USB 1.1, supporting speeds of 1.5, 12 and 480 Mbps. For
example, keyboard and mouse can be used with USB port at low speed, while printer and
USB memory stick will run at High-speed. Information can be transferred to a PC using
the Branson History Utility to view and process information. This can be useful when weld
CAUTION General Warning
Cooling air (80 SCHF) must be supplied to the converter through the
air inlet located at the front of the Actuator. Permanent damage to
the converter may result if air supply is not provided.
NOTICE
Be sure to set the down speed control to a slow setting, between 5
and 15, for an initial setup. The downspeed control knob has a set-
screw locking mechanism that can be used if desired.
NOTICE
Minimum stroke cannot be less than 1/4”.
