SEP 2005 MODEL 1000
INSTALLATION AND SETUP
3-26
(7) After confirming that all Interconnect Cable terminations are correct between the Analyzer
and the GC Controller, lift the Valve Driver Board from its resting position and place it over
the four holding screws.
(a) Reinstall the four thumb screws to secure the Valve Driver Board in place.
(8) If necessary, complete wiring connections between the Analyzer's Valve Driver Board and
any optional stream switch boards.
(9) If necessary, complete wiring for connecting AC power to the Analyzer, with proper
connections to hot, neutral, and ground; but do not turn on AC power to the Analyzer yet
(see CAUTION below; see details for AC power connection to Analyzer in Section 3.3.2,
this manual).
EQUIPMENT DAMAGE OR PERSONAL INJURY
Do not apply AC electrical power to the Analyzer or the GC Controller until all electrical
power, interconnection, and external signal connections have been verified, and proper
grounds have been made.
Failure to properly connect the GC unit may result in serious equipment damage or personal
injury.
(10) Leave the Analyzer's upper enclosure open if you need to connect sample and gas lines.
(You will need to manually operate the sample valve switches on the Valve Driver Board.)
(11) If necessary, proceed to Section 3.3.3 for instructions on connecting sample and gas lines to
the Analyzer.
