(2) Connect carrier gas to Analyzer. (DO NOT TURN ON GAS AT THIS TIME.)
See Appendix B, this manual, for a description of a dual-cylinder carrier gas manifold (P/N
3-5000-050) with these features:
- Carrier gas is fed from two bottles.
- When one bottle is nearly empty (100 psig), the other bottle becomes the primary
supply.
- Each bottle can be disconnected for refilling without interrupting GC operation.
(a) Use 1/4-inch stainless steel tubing to conduct carrier gas.
(b) Use dual-stage regulator: high side capacity 3000 psig; low side capacity 150 psig.
(3) Connect calibration standard gas to Analyzer. (DO NOT TURN ON GAS AT THIS TIME.)
(a) Use 1/8-inch stainless steel tubing to conduct calibration standard gas.
(b) Use dual-stage regulator: low side capacity up to 30 psig.
(c) Calibration gas inlet is identified in the applicable Sample Conditioning System
("S.C.S") drawing in the Analyzer drawings addendum to this manual. (See
drawings CE-16120, CE-16220, CE-16320, CE-16420, or CE-16520.)
When installing the calibration standard gas line, take care to follow the proper "S.C.S."
drawing in order to make the correct tubing connection to the auto-cal solenoid. Drawings are
included in this manual which address stream and column gas connections. Choose the
drawing that applies to your installation.
