Emerson Site Supervisor User Manual

Appendix A: Alarm Advisories • A-5
All Lights On System Alarm GlobalData All Lights On input in Global Data application has
turned ON to switch on all the lights.
HVAC Shutdown System Alarm GlobalData A Global Data application’s HVAC Shutdown input
has turned ON to shut down all HVAC systems.
REFR Shutdown System Alarm GlobalData A Global Data application’s REFR Shutdown input has
turned ON to shut down all suction groups, condens-
ers, and circuits.
HVAC Phase Loss System Alarm GlobalData A phase loss device connected to Global Data has
switched ON to shut down all HVAC systems.
REFR Phase Loss System Alarm GlobalData A phase loss device connected to Global Data has
switched ON to shut down all refrigeration systems.
Archive Percentage Full System Alarm LogGroup The controller supports the ability to archive log data
to the SD card if installed. The controller allows the
end user to specify on a per log group basis the desti-
nation of the archive. If configured and the SD card is
subsequently removed or if the SD card becomes
Archive Notice percentage full, a NOTICE advisory is
generated and log data archiving is suspended (Log
Archive disabled).
Demand Limit Exceeded Application
Alarm
UtilityMonitoring The application will provide an application alarm to
signal a high demand. The demand alarm limit and
alarm delay should be configurable. The demand alarm
delay is the amount of time the application will wait
after the Shed output turns on, before the demand
alarm is generated. Also, the Shed Output may be con-
figured to be controlled by either the average or instan-
taneous usage rate.
Heating Problem Device Alarm Emerson T-Stat Heating Two Hours – Thermostat did not see a rise in
supply temperature when heating was called for.
Heat Shutdown Device Alarm Emerson T-Stat Heat Continuous – In heat or backup heat mode, ther-
mostat shall open latching relay contacts if temperature
is over 10°F above setpoint.
Failed Sensor Device Alarm Emerson T-Stat Temperature Sensor Fail – Thermostat has detected a
failure of the internal space temperature sensor.
Stuck Key Device Alarm Emerson T-Stat A stuck key (closed) has been detected on the thermo-
stat.
Unexpected Temp Change Device Alarm Emerson T-Stat If heating or cooling is engaged, and either the indoor
temperature sensor reading, or the supply air tempera-
ture sensor reading starts moving the opposite way at a
higher rate than it was before the heating or cooling
was engaged, the thermostat shall report a diagnostic
message, and shut down the operation.
Cooling Problem Device Alarm Emerson T-Stat Cool Eight Hours – If cool runs for over 8 hours con-
tinuously, the thermostat shall set anticipator to zero
until call for cool is satisfied.
Proof Fail Device Alarm Emerson T-Stat Fan Not Detected – Any time, when the fan is acti-
vated and if the Fan Detect input is enabled, the Ther-
mostat shall check its status 15 seconds after the fan is
energized, and if the fan is not on, it shall disable any
active heat or cool calls, and report an alarm.
Alarm Items Category Cell Name Description
