5.12.2 Command-Alarm Matrix
LOAD 6 ALARM Load 6 Alarm
LP SWITCH ALARM Low Press. LP Switch
HP SWITCH ALARM High Press. HP Switch
ELECTRONIC LP Electronic low press
DGS DLT ALARM Digital Scroll High Discharge Line
temp
Command Description/Alarm Text
Keyboard LOCK The front panel is locked and cannot be
used.
Keyboard UNLOCKThe front panel is unlocked and can be
used.
Alarms Muting Silences the alarm output.
Table 5-8 - Diagnostic Alarms
Table 5-7 - XC645CX 2.5 Application Advisories
