5-14 • Site Supervisor Controller User Guide 2.0 026-1800 Rev 3 02-AUG-2016
5.7 Time Schedule
Application
The Time Schedule application schedules lighting or
occupancy state activities. The allowed number of Time
Schedule Applications is based on the total number of
applications allowed in the controller. Support for
additional applications may be added with a separate
license key.
5.7.1 Time Schedule Method
The Time Schedule application is enabled when the
ENABLE input is ON. The schedule feeds its time
schedule output and acts as an independent schedule.
The Time Schedule Types are:
Standard Schedule:
The user defines a “Standard Schedule” that specifies
the ON/OFF times for each day of the week, and the ON/
OFF times for the holidays/special days.
For the schedule, the ON/OFF times are absolute
times.
For the Standard Schedules the user may specify the
date range that the schedule is active. This allows the user
to have multiple schedules based on the time of year.
Master Schedule:
The Master Schedule feeds its time schedule output to
the Slave Schedule(s) or acts as an independent schedule.
Slave Schedule:
The user defines a “Standard Schedule” that spec fies
the ON/OFF times for each day of the week, and the ON/
OFF times for the holidays/special days. These ON/OFF
times have different implications depending on whether
the schedule is a master or slave type.
The Slave Schedule needs a Master Schedule as one of
its inputs. Provides offset capability to the Master's events.
The user defines a “Standard Schedule” that specifies the
ON/OFF times for each day of the week, and the ON/OFF
times for the holidays/special days. These ON/OFF times
have different implications depending on whether the
schedule is a master or slave type.
For Slave Schedules, the ON/OFF times are either
absolute times or relative times to the Master Schedule, in
which positive time represents how much time after and
negative time represents how much time ahead of what is
specified in the Master Schedule. There can be at most one
relative ON time and one relative OFF time for a single
day. For the Master Schedule, the ON/OFF times are
absolute times.
For the Standard Schedules the user may specify the
date range that the schedule is active. This allows the user
to have multiple schedules based on the time of year. The
schedules can be combined using a combiner application.
5.7.2 Standard Schedule
Each standard schedule is made up of up to 15 daily
event schedules. Each daily event schedule is made up of
two times (typically an On/Off pair). For each daily event
schedule the user can assign which days of the week that
daily schedule should be used (seven days plus four
holiday/special days). This allows a unique daily schedule
for each day of the week or one where it is followed
multiple days during the week. If a user needs more than
two On/Off events in one day, they can combine multiple
daily schedules together (they still are limited to 15 daily
event schedules per overall schedule).
5.7.3 Event Names
The user can assign an event name on each event. By
default the name of the event is Event x, where x is the
event number (1-15).
5.7.4 Maintenance Schedule
A user can define three maintenance schedule changes
for each time schedule.
The following information is included:
• START DATE - The start date at which the Time
Schedule will start ignoring its standard events and
following its maintenance overrides.
• START TIME - The start time at which the Time
Schedule will stop following its standard events and
start using its maintenance overrides. If you want
the maintenance override to be followed for the
entire day, leave this field set to 0:00 and the End
NOTE: Fan control is not directly affected by
a call for curtailment.
NOTE: The Schedule time ranges can be
modified by dragging the schedule bar to
adjust time.
Schedules (Master Slave) are now easier and
flexible to create during setup. The system can now
show all created schedules in the summary screen
(master and slave schedules).
