The four GTH pairs and two reference input clock differential pairs are routed by default to module connec-
tor B on modules equipped with ZU4/ZU5 devices. Please refer to Section 2.9.2 for details on the assembly
variants and MGT connectivity.
The GTH MGTs on the MPSoC device support data rates of 12.5 Gbit/sec.
The MPSoC devices equipped on the Mercury XU5 SoC module variants 4EV/5EV can support up to two
integrated PCIe Gen3 ×4 interfaces on the PL side, implemented using GTH transceivers. Simultaneous
usage of these interfaces is limited to the available hardware resources (number of transceivers and lane
mapping).
Warning!
It is recommended to use redrivers on the base board for PCIe Gen3 or other high-speed interfaces
implementations, and to perform channel simulation.
GTR Transceivers
There are four GTR MGT pairs and two reference input clock differential pairs on the Mercury XU5 SoC
module connected to I/O bank 505; these are routed by default to module connector B - refer to Section
2.9.2 for details on the assembly variants and MGT connectivity.
The naming convention for the GTR MGT I/Os is:
MGTPS_<FUNCTION>_<P
ACKAGE_PIN>_<POLARITY>.
For example, MGTPS_RX2_B28_N is located on pin B28 of PS GTR bank (bank 505), it is a receive pin and it
has negative polarity.
The standard Mercury XU5 SoC module variants that use regular MGT routing support the implementation
of a PCIe Gen2 ×4 interface.
Please note that when the PCIe hard block is used, it is not possible to use the Ethernet 0 interface. Ether-
net PHY 0 is connected to ETH 0 controller from the PS I/O bank 501; one of the Ethernet TX data signals
is shared with the PCIe reset signal (PERST#). Refer to Sections 2.9.2 and 2.9.7 for details on the PERST#
connection.
The GTR pairs support data rates of 6 Gbit/sec and can be used for the implementation of several interfaces
such as PCIe Gen2 ×4, USB 3.0, DisplayPort, SATA, or Ethernet SGMII. Please refer to the Zynq UltraScale+
MPSoC Technical Reference Manual [19] and to the Zynq UltraScale+ MPSoC Overview [23] for details.
A 100 MHz LVDS oscillator and a 27 MHz CMOS oscillator provide reference clock inputs to the PS GTR bank
505. Please refer to Section 2.12 for details.
Warning!
The maximum data rate on the MGT lines on the Mercury XU5 SoC module depends on the routing
path for these signals. Adequate signal integrity over the full signal path must be ensured when using
MGTs at high performance rates.
D-0000-445-001 31 / 64 Version 07, 25.07.2019
