Enclustra Mercury XU5 User Manual

2.2 Module Configuration and Product Codes
Table 1 describes the available standard module configurations. Custom configurations are available; please
contact Enclustra for further information.
Product Code MPSoC DDR4 (PS) DDR4 (PS) DDR4 (PL) Temperature
SDRAM ECC SDRAM Range
ME-XU5-2CG-1E-D10H
1
XCZU2CG-
1SFVC784E
1 GB 7 512 MB 0 to +85
◦
C
ME-XU5-2EG-1I-D11E XCZU2EG-
1SFVC784I
2 GB 3 512 MB -40 to +85
◦
C
ME-XU5-3EG-2I-D11E XCZU3EG-
2SFVC784I
2 GB 3 512 MB -40 to +85
◦
C
ME-XU5-4CG-1E-D11E-G1
2
XCZU4CG-
1SFVC784E
2 GB 3 512 MB 0 to +85
◦
C
ME-XU5-4EV-1I-D11E XCZU4EV-
1SFVC784I
2 GB 3 512 MB -40 to +85
◦
C
ME-XU5-4EV-1I-D11E-G1
2
XCZU4EV-
1SFVC784I
2 GB 3 512 MB -40 to +85
◦
C
ME-XU5-5EV-1E-D11E XCZU5EV-
1SFVC784E
2 GB 3 512 MB 0 to +85
◦
C
ME-XU5-5EV-2I-D12E XCZU5EV-
2SFVC784I
4 GB 3 1 GB -40 to +85
◦
C
ME-XU5-5EV-2I-D12E-G1
2
XCZU5EV-
2SFVC784I
4 GB 3 1 GB -40 to +85
◦
C
ME-XU5-5EV-3E-D13E XCZU5EV-
3SFVC784E
8 GB 3 2 GB 0 to +85
◦
C
Table 1: Standard Module Configurations
1 2
The product code indicates the module type and main features. Figure 3 describes the fields within the
product code.
1
This variant supports only half of the DDR4 bandwidth on the PS side (32-bit interface instead of 64-bit). Refer to Section 2.15 for
details.
2
G1 assembly variants offered for migration purposes or for cases where the end application does not require GTR transceivers,
but instead more regular I/Os. It can be used when porting an existing design from Mercury ZX1 or ZX5 to Mercury XU5 SoC module.
Please refer to Section 2.9.2 for details on assembly options and migration guidelines. This variant was referred to as “X1” variant in
previous user manual versions.
