Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 115
HYDR. PRESS MAX.
Entry
Enter the maximum hydrostatic pressure to be expected.
The input limits for the calibration (editing limits) are derived from the value entered. The
closer the value entered corresponds to the maximum hydrostatic pressure to be
expected, the more accurate the measurement result.
Factory setting:
High sensor limit (→ See PRESS. SENS HILIM, Page 140)
DAMPING VALUE
Entry
Enter damping time (time constant τ).
The damping affects the speed at which all subsequent elements, such as the on-site
display, measured value and OUT value of the Analog Input Block react to a change in the
pressure.
Input range:
0.0...999.0 s
Factory setting:
2.0 s or as per order specifications
ToF Tool, Table 8: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL MODE "Pressure linearized"
Parameter name Description
