Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 129
P01-xMx7xxxx-19-xx-xx-xx-036
Fig. 30: EXTENDED SETUP function group
→ For the "Pressure" measuring mode, see Page 129, ToF Tool, table 11
→ For the "Level" measuring mode, see Page 129, ToF Tool, table 12
→ For the "Flow" measuring mode, see Page 130, ToF Tool, table 13
DAMPING VALUE
Entry
Enter damping time (time constant τ).
The damping affects the speed at which all subsequent elements, such as the on-site
display, measured value and OUT value of the Analog Input Block react to a change in the
pressure.
Input range:
0.0...999.0 s
Factory setting:
2.0 s or as per order specifications
ToF Tool, Table 10: OPERATING MENU → SETTINGS → BASIC SETUP "Flow"
Parameter name Description
*
*
Parameters marked with an asterisk "*"
are not always displayed. The display
depends on the settings of other parameters,
see the following Table.
OPERATING MENU
MEASURED VALUE
QUICK SETUP
BASIC SETUP
DISPLAYSETTINGS
POSITION ADJUSTMENT
EXTENDED SETUP
FlowPressure Level
TEMP. EING. UNIT TEMP. EING. UNIT
LOW FLOW CUT-OFF
SET L. FL. CUT-OFF
ADJUST DENSITY
PROCESS DENSITY
TEMP. EING. UNIT
ToF Tool, Table 11: OPERATING MENU → SETTINGS → EXTENDED SETUP "Pressure"
Parameter name Description
Prerequisite:
• MEASURING MODE = pressure
Note:
• See also Page 74 ff, Section 7 "Pressure measurement (ToF Tool)".
TEMP. ENG. UNIT
Selection
Select the unit for the temperature measured values.
→ See also PCB TEMPERATURE (Page 139) and SENSOR TEMP. (Page 143).
Options:
•°C
•°F
•K
•R
Factory setting:
°C
ToF Tool, Table 12: OPERATING MENU → SETTINGS → EXTENDED SETUP "Level"
Parameter name Description
Prerequisite:
• MEASURING MODE = level
Note:
• See also Page 75 ff, Section 7 "Level measurement (ToF Tool)".
