Description of parameters (ToF Tool) Cerabar S/Deltabar S
128 Endress+Hauser
MASS FLOW UNIT
Selection
Select mass flow unit.
When a new flow unit is selected, all flow-specific parameters are converted and
displayed with the new unit within a flow mode (FLOW-MEAS. TYPE). When the flow
mode is changed, conversion is not possible.
Prerequisite:
• FLOW-MEAS. TYPE = mass p. cond.
Options:
• g/s, kg/s, kg/min, kg/min, kg/h
• t/s, t/min, t/h, t/day
•oz/s, oz/min
• lb/s, lb/min, lb/h
• ton/s, ton/min, ton/h, ton/day
• User unit, → see also the following parameter description for CUSTOMER UNIT F and
CUST. UNIT FACT. F
Factory setting:
kg/s
CUSTOMER UNIT F
Entry
Enter text (unit) for customer-specific flow unit.
You can enter a maximum of eight alphanumeric characters here. → See also CUST.
UNIT FACT. F.
Prerequisite:
• UNIT FLOW = user unit
• NORM FLOW UNIT = user unit
• STD. FLOW UNIT = user unit
• MASS FLOW UNIT = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. F
Entry
Enter conversion factor for a customer-specific flow unit. The conversion factor must be
entered in relation to an appropriate SI unit, e.g. m
3
/s for the "Volume p. cond." flow
mode. → See also CUSTOMER UNIT F.
Prerequisite:
• UNIT FLOW = user unit
• NORM FLOW UNIT = user unit
• STD. FLOW UNIT = user unit
• MASS FLOW UNIT = user unit
Example:
– You want the measured value to be displayed in "bucket/h".
– MEASURED VALUE =0.01 m3/s i 3600 bucket/h
– Entry CUSTOMER UNIT F: bucket/h
– Entry CUST. UNIT FACT. F: 360000
– Result: MEASURED VALUE = 3600 bucket/h
Factory setting:
1.0
MAX. FLOW
Entry
Enter maximum flow of primary device.
→ See also layout sheet of primary device. The maximum flow is assigned to the
maximum pressure which you enter via MAX PRESS. FLOW.
Factory setting:
1.0
MAX PRESS. FLOW
Entry
Enter maximum pressure of primary device.
→ See layout sheet of primary device. This value is assigned to the maximum flow value
(→ see MAX. FLOW).
Factory setting:
High sensor limit (→ see PRESS. SENS HILIM, Page 140)
ToF Tool, Table 10: OPERATING MENU → SETTINGS → BASIC SETUP "Flow"
Parameter name Description
