Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 139
TAG_DESC
Entry
Enter tag name e.g. TAG number (max. 32 alphanumeric characters).
Factory setting:
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ or as per order specifications
ADDITIONAL INFO
Entry
Enter tag description (max. 32 alphanumeric characters).
Factory setting:
Empty field or as per order specifications
DEVICE DESIGN.
Display
Displays the device designation and order code.
HARDWARE REV.
Display
Displays the revision number of the main electronics
e.g.: V01.00.00
SOFTWARE VERSION
Display
Displays the software version
e.g.: V02.00.00
CONFIG RECORDER
Display
Displays the configuration counter.
This counter is increased by one with each change to a parameter or group. The counter
counts to 65535 and then starts again at zero. Changes in the parameters of the DISPLAY
function group do not increase the counter.
PCB TEMPERATURE
Display
Displays the measured temperature of the main electronics.
ALLOWED MIN. TEMP
Display
Displays the lower temperature limit of the main electronics.
ALLOWED MAX. TEMP
Display
Displays the upper temperature limit of the main electronics.
DIP STATUS
Display
Displays the status of DIP switch 1 on the electronic insert.
You can lock or unlock parameters relevant to the measured value with DIP switch 1. If
operation is locked by means of the INSERT PIN No. parameter, you can only unlock
operation again by means of this parameter. (→ INSERT PIN NO, see Page 147.)
→ See also Operating Instructions BA301P (Deltabar S) or BA302P (Cerabar S), Section
5.6 "Locking/unlocking operation".
Display:
• On (locking switched on)
• Off (locking switched off)
Factory setting:
Off (locking switched off)
ToF Tool, Table 19: OPERATING MENU → TRANSMITTER INFO → PROCESS CONNECTION
Parameter name Description
Pmax PROC. CONN.
Entry
For entering and displaying the maximum permitted pressure of the process connection.
Factory setting:
In accordance with nameplate data (→ see also Operating Instructions BA301P
(Deltabar S) or BA302P (Cerabar S), Section 2.1.1 nameplate)
PROC. CONN. TYPE
Selection
For selecting and displaying the process connection type.
Options:
•Not used
•Unknown
• Special
•Oval flange
• Thread female
•Thread male
•Flange
•Remote seal
