11.2.2 Analog Input Block
If the Analog Input Block receives an input or simulation value with the status BAD, the Analog
Input Block uses the failsafe mode defined in the FSAFE_TYPE
1
parameter.
The following options are available by means of the FSAFE_TYPE
1
parameter:
• Last Good Value
The last valid value is used for further processing with the status UNCERTAIN.
• Fail SafeValue
The value specified by means of the FSAFE_VALUE
1
parameter is used for further processing with
the status
UNCERTAIN.
•Wrong Value
The current value is used for further processing with the status BAD.
Factory setting:
• FSAFE_TYPE
1
: FsafeValue
•FSAFE_VALUE
1
: 0
!
Note!
The failsafe mode is also activated if the "Out of Service" option was selected by means of the
MODE_BLK parameter.
11.3 Confirming messages
Depending on the settings for the ALARM_HOLD_ON_TIME/ALARM DISPL. TIME and
ACKNOWLEDGE_ALARM_MODE/ACK. ALARM MODE parameters, the following measures
should be taken to clear a message:
1 These parameters are not available by means of the ToF Tool operating program.
Settings
1
1) FF configuration program: The parameters are in the Diagnostic Transducer Blocks.
ToF Tool: Menu path for ALARM DISPL. TIME and ACK. ALARM MODE: OPERATING MENU → DIAGNOSTICS
→ MESSAGES
Measures
– ALARM_HOLD_ON_TIME//
ALARM DISPL. TIME = 0 s
– ACKNOWLEDGE_ALARM_MODE/
ACK. ALARM MODE = off
– Rectify cause of the message (see also Section 11.1).
– ALARM_HOLD_ON_TIME/
ALARM DISPL. TIME > 0 s
– ACKNOWLEDGE_ALARM_MODE/
ACK. ALARM MODE = off
– Rectify cause of the message (see also Section 11.1).
– Wait for the alarm display time to elapse.
– ALARM_HOLD_ON_TIME/
ALARM DISPL. TIME = 0 s
– ACKNOWLEDGE_ALARM_MODE/
ACK. ALARM MODE = on
– Rectify cause of the message (see also Section 11.1).
– Confirm message using ACKNOWLEDGE_ALARM/ACK. ALARM
parameter.
– ALARM_HOLD_ON_TIME/
ALARM DISPL. TIME > 0 s
– ACKNOWLEDGE_ALARM_MODE/
ACK. ALARM MODE = on
– Rectify cause of the message (see also Section 11.1).
– Confirm message using ACKNOWLEDGE_ALARM/ACK. ALARM
parameter.
– Wait for the alarm display time to elapse. If a message appears and the alarm
display time elapses before the message has been acknowledged, the message
will be cleared once it has been acknowledged.
