Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 99
P01-xMx7xxxx-19-xx-xx-xx-030
Fig. 22: BASIC SETUP function group for the "pressure" measuring mode
*
*
*
Parameters marked with an asterisk "*"
are not always displayed. The display
depends on the settings of other parameters,
see the following Table.
Flow
Pressure
Level
PRESS. ENG. UNIT
CUSTOMER UNIT P
CUST. UNIT FACT. P
DAMPING VALUE
MEASURING MODE
OPERATING MENU
MEASURED VALUE
QUICK SETUP
BASIC SETUP
DISPLAYSETTINGS
POSITION ADJUSTMENT
EXTENDED SETUP
ToF Tool, Table 5: OPERATING MENU → SETTINGS → BASIC SETUP "Pressure"
Parameter name Description
Prerequisite:
• MEASURING MODE = pressure
Note:
See also
– Page 92, ToF Tool, table 1: QUICK SETUP
– Page 129, ToF Tool, table 11: EXTENDED SETUP
– Page 142 ff, ToF Tool, table 21: PROCESS VALUES
– Page 74 ff, Section 7 "Pressure measurement (ToF Tool)".
MEASURING MODE
Selection
Select the measuring mode.
The operating menu is structured according to the selected measuring mode.
!
Note!
When the measuring mode is changed, no conversion takes place. The device has to be
recalibrated if the measuring mode is changed. → See also Page 74, Section 7 "Pressure
measurement (ToF Tool)".
Options:
• Pressure
• Level
• Deltabar S: flow
Factory setting:
Pressure
