Description of parameters (FF configuration program) Cerabar S/Deltabar S
22 Endress+Hauser
Block configuration when delivered
The block model shown below illustrates the block configuration when the device is delivered.
P01-xMx7xxxx-02-xx-xx-xx-000
Fig. 7: Block configuration when delivered
Cerabar S
The Pressure Transducer Block returns the Primary Value (pressure measured value) and the
Secondary Value (sensor temperature). Primary Value and Secondary Value are each transferred to
one Analog Input Block by means of the CHANNEL parameter (→ see also Page 67, parameter
description CHANNEL).
The Discrete Output, PID, Arithmetic, Signal Characterizer, Input Selector and Analog Alarm Block
are not connected in the as-delivered state.
Deltabar S
The Pressure Transducer Block returns the Primary Value (pressure measured value) and the
Secondary Value (sensor temperature). In the Totalizer Transducer Block, the flow is totalized in
the "Flow" measuring mode and output by means of the TOTALIZER_1_VALUE/TOTALIZER 1
parameter. Primary Value, Secondary Value and TOTALIZER_1_VALUE are each transferred to one
Analog Input Block by means of the CHANNEL parameter (→ see also Page 67, parameter
description CHANNEL).
The Discrete Output, PID, Arithmetic, Signal Characterizer, Input Selector and Analog Alarm Block
are not connected in the as-delivered state.
!
Note!
Please note that the links between the blocks are deleted and the FF parameters are reset to the
default values following a reset by means of the RESTART parameter in the Resource Block,
"Default" option.
Pressure
Transducer Block
Analog Input Block 1
CHANNEL = 1
L_TYPE = Direct
Analog Input Block 2
CHANNEL = 2
L_TYPE = Direct
Analog Input Block 3
CHANNEL = 6
L_TYPE = Direct
Totalizer
Transducer Block
Display
Transducer Block
Diagnostic
Transducer Block
Service
Transducer Block
Primary value
Secondary value
Resource Block
PID Block
Analog Alarm Block
Input Selector Block
Signal Characterizer
Block
Discrete Output
Block
Arithmetic Block
Deltabar only
Measured variable
Sensor
Signal evaluation
Display
with scaling
TOTALIZER 1
