Description of parameters (FF configuration program) Cerabar S/Deltabar S
66 Endress+Hauser
ALARM_SUM
Display, Selection
Index: 22
Data type: DS-74
Access: Auto; Man, OOS
The ALARM_SUM parameter is a structured parameter consisting of four elements.
CURRENT
• Displays the current status of the process alarms in the Analog Input Block.
The following alarms are possible: HiHiAlm, HiAlm, LoLoAlm, LoAlm and
BlockAlm.
UNACKNOWLEDGED
• Displays the process alarms not confirmed.
UNREPORTED
• Displays the process alarms not reported.
DISABLED
• Possibility to deactivate process alarms.
ALERT_KEY
Entry
Index: 4
Data type: Unsigned8
Access: Auto, Man, OOS
Enter the identification number for the device or for each individual block.
The host system uses this identification number to sort alarm and event messages and initiate
further processing.
Input range:
1...255
Factory setting:
0
BLOCK_ALM
Display, Selection
Index: 21
Data type: DS-72
Access: Auto, Man, OOS
The BLOCK_ALM parameter is a structured parameter consisting of five elements.
UNACKNOWLEDGED
• If the "Deactivated" option was selected for the alarm occurring via the ACK_OPTION
parameter, this alarm can only be acknowledged via this element.
ALARM_STATE
• Displays the current block status with information on the pending configuration, hardware
or system errors. The following block alarm messages are possible for the Analog Input
Block:
–Simulate Active
– Input Failure
– Block Config Error
–Out of Service
TIME_STAMP
• Displays the time the alarm occurred.
SUB_CODE
• Displays the reason why the alarm was reported.
VALUE
• Displays the value of the parameter at the time the alarm was reported.
Analog Input Block
Parameter Description
