Description of parameters (ToF Tool) Cerabar S/Deltabar S
94 Endress+Hauser
P01-xMx7xxxx-19-xx-xx-xx-027
Fig. 19: Quick Setup menu for the "Level" measuring mode
1), 2) 3)
POS. INPUT VALUE
Cerabar S – Absolut
pressure sensors
Deltabar S,
Cerabar S – Gauge
pressure sensors
OPERATING MENU
1) LEVEL MODE = "Linear"
and CALIBRATION MODE = "dry"
3) LEVEL MODE = "LInear"
or "Height Linearized" and
CALIBRATION MODE = "wet"
POS. ZERO ADJUST
EMPTY CALIB.
FULL CALIB.
DAMPING VALUE
Pressure
Level
MEASURED VALUE
QUICK SETUP
MEASURING MODE
2) LEVEL MODE = "Pressure Linearized"
Flow
ToF Tool, Table 2: QUICK SETUP "Level"
Parameter name Description
This menu displays the most important parameters for the "Level" measuring mode.
Prerequisite:
• MEASURING MODE = level
Note:
See also
– Page 101 ff, ToF Tool, tables 6 to 9: BASIC SETUP
– Page 129 ff, ToF Tool, table 12: EXTENDED SETUP
– Page 132 ff, ToF Tool, table 14: LINEARISATION
– Page 143 ff, ToF Tool, table 22: PROCESS VALUES
– Page 75 ff, ToF Tool, Section 8 "Level measurement (ToF Tool)".
MEASURING MODE
Selection
Select the measuring mode.
The operating menu is structured according to the selected measuring mode.
!
Note!
When the measuring mode is changed, no conversion takes place. The device has to be
recalibrated if the measuring mode is changed. → See also Page 75, Section 8 "Level
measurement (ToF Tool)".
Options:
• Pressure
• Level
• Deltabar S: flow
Factory setting:
Pressure
