Endress+Hauser Levelflex FMP53 - Switch-on delay

Levelflex FMP51, FMP52, FMP54 Description of device parameters (operating menu)
Endress+Hauser 149
Additional information
The switching behavior depends on the relative position of the two switch points.
Switch-on point > Switch-off point:
The output is closed if the measured value exceeds the switch-on point.
The output is opened if the measured value falls below the switch-off point.
t
t
A
B
C
D
A0015585
A Switch-on point
B Switch-off point
C Output closed
D Output opened
Switch-on point < Switch-off point:
The output is closed if the measured value falls below the switch-on point.
The output is opened if the measured value exceeds the switch-off point.
t
t
B
A
C
D
A0015586
A Switch-on point
B Switch-off point
C Output closed
D Output opened
Switch-on delay
Navigation
Setup ® Advanced setup ® Switch output ® Switch-on delay
