Endress+Hauser Mycom CLM 152 Operating Instructions

13.1.4 General technical data
General data
Manufacturer Endress+Hauser
Instrument name Mycom CLM 152
Limit and alarm functions
Function Limit contactor
Function type MIN or MAX
Setpoint settings (in absolute values) 0 ... 100 % of display range
Hysteresis for switch contacts (in absolute figures) 1 ... 10 % of display range
On / off delay 0 ... 7200 s
Alarm threshold 0.5 ... 100 % of display range
Alarm delay 0 ... 6000 s
Electrical connection data
Power supply AC 24 / 100 / 115 / 200 / 230 V +10 / –15 %
Frequency 47 ... 64 Hz
Power supply DC 24 V, +20 / –15 %
Power consumption max. 10 VA
Contact outputs (optional)
Floating change-over contacts (Ex version: optocoupler)
switchable as NO or NC contact
Switching current max. 3 A
Switching voltage max. 250 VAC / 125 VDC
Switching power max. 750 VA
Signal outputs
2 x 0 / 4 ... 20 mA, electrically isolated from other circuits,
but not between outputs
Isolation voltage 276 V
rms
Current output
Current range 0/4 ... 20 mA
Measurement deviation
≤ 0.2 % of upper range value
Load
max 600 Ω
Terminals, maximum cable cross-section 2,5 mm
2
Temperature measurement
Temperature sensor Pt 100 (three-wire circuit)
Measuring range (MR, also displayable in °F and K) –35 ... +250 °C
Measured value resolution 0.1 °C
Measurement deviation at temp. output (as per IEC 746) 0 ... 100 °C: ± 0.5 K; remaining range: ± 1 K
Reproducibility max. 0.1 % of MR
Temperature signal output transfer range
adjustable ∆ 28.5 ... ∆ 285 °C
Concentration measurement
Specifications subject to change
Selection Conductivity range Concentration
NaOH 0.0 mS/cm ... 410 mS/cm 0 ... 15%
HNO
3
0.0 mS/cm ... 781 mS/cm 0 ... 20 %
H
2
SO
4
0.0 mS/cm ... 723 mS/cm 0 ... 20 %
H
3
PO
4
0.0 mS/cm ... 73 mS/cm 0 ... 12 %
USER 1 ... 4
2)
0.0 µS/cm ... 2000 mS/cm 0 ... 99.99 %
Appendix Mycom CLM 152
82 Endress+Hauser
