7.6 Substance selection / Concentration measurement
Note:
This menu only appears when the
concentration measurement is set as
the measuring type (see Parameter
menu, Chap. 7.1.1).
→ Instrument data
→ Substance
selection
Function Selection Factory setting
Select measuring range with
remote switch-over activated
Measuring range 1 ... 4
Measuring
range 1
Select substance
NaOH
HNO3 (fixed, no further
H3PO4 settings required)
H2SO4
USER1 ... USER4 (freely selectable)
NaOH
Für USER1 ... USER4
Enter substance name
Substance name, max. 5 chars.
0 ... 9; a ... Z
USER 1
Enter number of support points for
substance concentration curve
Support point substance curve,
2...10
2
A specific concentration is
assigned to a conductivity value
at every support point
1
Concentration Conductivity
00.00 % 0.000 mS/cm
Enter number of support points for
Tc table
Support points for Tc table, 2 ... 10 2
A temperature coefficient is
assigned to a temperature value
for each support point
2
Temperature Temp. coefficient
000.0 °C 00.00 %/K
1
Concentration values:
The entered values must be strictly monotonic increasing or decreasing.
Conductivity values:
The entered values must be strictly monotonic increasing or decreasing. They must have a
minimum distance.
a) If the successive conductivity values are in the same switching range, then the minimum
distance is 0.5 % of the end value of the switching range.
b) If the successive conductivity values are in different switching ranges, then the minimum
distance is 0.5 % of the end value of the higher switching range.
If the mininum distance is not reached, then an error message is given and the table is
marked as invalid.
Switching range Minimum distance Switching range Minimum distance
0.0 ... 200.0 nS/cm 1 nS/cm 200 ... 2000 µS/cm 10 µS/cm
0.200 ... 2.000 µS/cm 10 nS/cm 2.00 ... 20.00 mS/cm 100 µS/cm
2.00 ... 20.00 µS/cm 100 nS/cm 20.0 ... 200.0 mS/cm 1 mS/cm
20.0 ... 200.0 µS/cm 1 µS/cm 200 ... 2000 mS/cm 10 mS/cm
After entry of a substance table, the table elements are checked for validity. The concentration
and conductivity values are checked separately.
2
The temperature values must be entered strictly monotonic increasing and with a difference of
minimum 10 K. The Tc values are not subject to check. After entry of a Tc table, it is checked
for validity.
}
PARAM
Instrument configuration Mycom CLM 152
52 Endress+Hauser
