6.5 Measured value display formats
Press ↑ and ↓ to select between different
display formats for the screens. There are
differences in the size of digits and the
number of additional information items.
Note:
A contact state display only appears
if one or two contacts are configured
as limit contactors.
Conductivity measurement
Single-
circuit
1st meas.
value
display
Main display: Conductivity measured value in mS/cm or µS/cm
(large characters for reading from a distance)
Suppl. info: Measuring range (only for meas. range switch-over)
2nd meas.
value
display
Main display: Conductivity measured value in mS/cm or µS/cm
Suppl. info: Measuring range (only for remote measuring range
switch-over),
Type of temperature compensation,
Substance measured,
Current compensation temperature
3rd meas.
value
display
Main display: Conductivity measured value in mS/cm or µS/cm
Suppl. info: Same as 2nd meas. value display plus
contact states (limit contactor only)
Difference
1st meas.
value
display
Main display: Differential conductivity measured value (∆CD)
in mS/cm or µS/cm (large characters)
Suppl. info: Measuring range (only for meas. range switch-over)
2nd meas.
value
display
Main display: Differential conductivity measured value (∆CD)
in mS/cm or µS/cm
Suppl. info: Measuring range (only for meas. range switch-over),
Type of temperature compensation,
Substance measured,
Current compensation temperature
3rd meas.
value
display
Main display: Differential conductivity measured value (∆CD)
in mS/cm or µS/cm
Suppl. info: Same as 2nd meas. value display plus
contact states (limit contactor only)
4th meas.
value
display
Main display: Conductivity measured value channel 1 (CD1)
in mS/cm or µS/cm
Suppl. info: Same as 3rd meas. value display
5th meas.
value
display
Main display: Conductivity measured value channel 2 (CD2)
in mS/cm or µS/cm
Suppl. info: Same as 3rd meas. value display
Concentration measurement
Single-
circuit
1st meas.
value
display
Main display: Concentration measured value in % (large characters)
Suppl. info: Measuring range (only for meas. range switch-over)
Substance name
2nd meas.
value
display
Main display: Concentration measured value in %
Suppl. info: Same as 1st meas. value display plus
Type of temperature compensation,
Current compensation temperature
3rd meas.
value
display
Main display: Concentration measured value in %
Suppl. info: Same as 2nd meas. value display plus
contact states (limit contactor only)
4th meas.
value
display
Main display: Concentration measured value in %
Suppl. info: Same as 1st meas. value display plus
Conductivity measured value
5th meas.
value
display
Main display: Concentration measured value in %
Suppl. info: Same as 3rd meas. value display plus
Conductivity measured value
