7.2 Current output
7.2.1 Current output
Current output signal: characteristics and allocation
→ Instrument data
→ General settings ☞ 7.2.1
→ Current output 1 ☞ 7.2.1
→ Current output 2 ☞ 7.2.1
Function Selection Factory setting
General
Current monitoring
(Cable break activates alarm
contact, error message 15 / 16)
inactive
active
inactive
Erro current (output on»alarm«
to current output 1 and 2)
Off (no error current)
Min current
1)
Max current
2)
Off
Hold type
Fixed current value
Last measured current
fixed current
value
Hold current (only on
selection of »fixed current value«)
0.00 ... 22.00 mA 20.00 mA
Current output 1
Measuring current range 0 ... 20 mA or 4 ... 20 mA 4 ... 20 mA
Outputdamping 1.0 ... 20.0 mA/s 20.0 mA/s
Select Characteristic
for output signal
for concentration: linear
for conductivity:
linear, bilinear, logarithmic,,
table characteristic only for single
circuit
for resistance:
linear, bilinear, logarithmic
linear
Select Remote switch-over
measuring range (only for activated
remote switch-over, see Parameter
menu, Chapter 7.1.1)
Measuring range 1 ... Measuring
range 4
measuring
range 1
Enter measuring range limits of
selected characteristic
Setting options and factory settings
see under A) to D) (next page)
Note
When »last
measured value« is
set, the value is
saved. When the
instrument is
restarted with hold
active, the saved
value is output.
PARAM
lm152e07.chp
Mycom CLM 152 Instrument configuration
Endress+Hauser 41
