Proline Prowirl 73
Endress+Hauser 7
!
Note!
• The individual functions are described in the "Description of Device Functions" section (ä 95).
• The display returns to the QUICK SETUP COMMISSION cell (ä 109) if you press the P key combination (Esc)
during parameter interrogation. The configuration settings already made remain valid, however.
m
The following parameters are reset to the factory setting if the fluid selected is changed:
In group Parameter
User interface  100% value line 1, 100% value line 2
Current output  All parameters
Frequency output  All parameters
Process parameter  All relevant parameters
n
Only the output (current output or frequency output) not yet configured is offered for selection after the first cycle.
o
The "YES" option appears as long as a free output is available. "NO" is displayed when no further outputs are
available.
p
When "YES" is selected, the volume flow is assigned to line 1 of the local display and the temperature to line 2.
q
If "HART INPUT GAUGE" or "HART INPUT ABSOLUTE" is selected in the PRESSURE TYPE function, the HART
INPUT field automatically switches to "PRESSURE".
If "HART INPUT ABSOLUTE" or "PREDEFINED VALUE" is selected, the AMBIENT PRESSURE field is not displayed.
If "PREDEFINED VALUE" is selected, the OPERATING PRESSURE field is displayed.
If "PREDEFINED VALUE" is selected, the ERROR VAL. PRESS field is not displayed.
r
If "SATURATED STEAM DELTA HEAT" or "WATER DELTA HEAT" is selected, the following notice message is
displayed: "EXTERNAL TEMPERATURE SENSOR REQUIRED".
s
If "SATURATED STEAM DELTA HEAT" or "WATER DELTA HEAT" is selected, the HART INPUT field automatically
switches to "TEMPERATURE".
t
Only data for the gas phase are available for these fluids.
u
These functions are only called up if the OTHER option was selected in one of the functions GAS TYPE 1 to 8.
v
The entry only appears if  was selected in the GAS TYPE 1 to 8 function.
