Document number: ED.03783.00.001.ENG rev 4 Page 100 of 153
6.4.2.11 COG of the complete system
To show the COG of the complete system, click COG All Units in the menu bar.
A new window pops up, on which is shown:
- The position of the expected COG.
(You entered it in the Expected load field of the Settings menu.)
- The measured COG as a result of measured oil pressures of the main jacks
- The positions of all units
(You entered them in the Expected load field of the Settings menu.)
6.4.2.12 Hysteresis
To set “Hysteresis”, click in the menu bar on the main screen on Hysteresis.
When switched on, the movements of the main jacks are synchronised: their heights are kept
equally within a certain bandwidth, by regulating their extending / retracting speeds.
