Document number: ED.03783.00.001.ENG rev 4 Page 55 of 153
5.2 How to assemble the system
This chapter describes how to assemble the system:
• Electrically
• Mechanically
No hydraulic connections have to be assembled; all hydraulics are integrated in the units.
5.2.1 Electrically
The units, the smartbox and the laptop have to be connected to each other as one of the two
configurations as shown below, depending on your own preferences:
Proceed as follows:
