JS500

NB: The four cylinders of a unit ar not connected to each other hydraulically.
All of them form separate oil circuits.
3.1.2 The barrel
A pile of barrels bears the load.
3.1.3 The top barrel
The top barrel is provided with a swivel. On top of two swivels, a header beam can be fitted.
Insertion system
(automatic version)
Mini-jack
Hydraulic power unit
Electro cabinet
End Barrel
Hydraulic power unit
Swivel
Electro cabinet
Main-jack
Lifting lug
recess, where the mini-jacks
fetch the barrel
