8.2.2 Error reports of the units
Ident
Error description
Possible solution
0001
Communication error. Check data
connection and reconnect
Overhaul system firewall settings if not able to
connect
0002
Stroke measurement below minimum.
Broken wire?
Check cables, connectors and mechanical
attachment
0003
Stroke measurement exceeds
maximum. Shortcut?
0004
Load pick up error
Adjust expected load. Check preload stroke and
mini-jack state
0005
Load drop off error
Adjust expected load. Check preload stroke
0006
Top anchor open timeout
Adjust timeout value and check top anchor
hydraulics and sensors
0007
Top anchor close timeout
0008
Bottom anchor open timeout
Adjust timeout value and check bottom anchor
hydraulics and sensors
0009
Bottom anchor Close timeout
0010
Unit design load overload
Reduce load
0011
Stroke measurement exceeds minimum
Stroke measurement exceeds minimum. Shortcut?
0012
Bottom pressure reading exceeds
maximum. Shortcut?
Stroke measurement exceeds maximum.
Shortcut?
0013
Rod pressure reading below minimum.
Broken wire?
Rod pressure reading exceeds minimum.
Shortcut?
0014
Rod pressure reading exceeds
maximum. Shortcut?
Rod pressure reading exceeds maximum.
Shortcut?
0015
Top anchor closed during calibration
process"
Open top anchors in manual mode
0016
Expected load overload
Adjust expected load settings
0017
Emergency circuit active. Press blue
button on smartbox
Check hardware assignment. RS485 dongles in
place?
0018
Local operation active
Remote control disabled
0019
Powerpack failure
Stop all engines, check powerpack instruments
0020
Emergency stop activated on Unit
Check powerpack and reset emergency stop on
Unit
0021
Preload pick-up error
Check expected load and preload stroke setting
0022
Both anchos open
Close at least one anchor
0023
Mini jack status fault
Make sure all mini jacks status are equal
0024
Unit not assigned
Open harware assign page and assign the correct
hardware to the unit
0025
Hydraulic oil Level Low
Refill hydraulic oil
0026
Hydraulic oil level too low
Do not use system. Refill hydraulic oil
0027
Oil temperature too high
Do not use system. Check powerpack for air flow
obstructions
0028
Delta stroke fault
Check hoses and connections for leakage
0029
Delta load fault
Check hoses and connections for leakage, check if
there are no obstructions
0030
Safety switch active
Check calibration and setting of the main jack, do
not continu if problem isn't resolved
0031
Bottompressure exceeds maximum
Check oil pressure and pressuresensor
0032
Rodpressure exceeds maximum
Check oil pressure and pressuresensor
0033
Rodpressure during extending exceeds
maximum
Check connection of the oil hoses
0034
Mini jack retraction fault
Check hydraulic hoses and sensor wiring
0035
Mini jack extension fault
0038
Strokesensor Fault Nr 1.
Stroke sensor is more then 10mm difference
0039
Strokesensor Fault Nr 2.
Stroke sensor is more then 10mm difference
0040
Strokesensor Fault Nr 3.
Stroke sensor is more then 10mm difference
0041
Strokesensor Fault Nr 4.
Stroke sensor is more then 10mm difference
0042
More than 2 safety switches activated
Check Cylinder strokes
