6.4.3.2 Logging of system data
Always when the main jacks are extending of retracting, data is logged with a periodicity of 20
sec. The data is written into a file. The following items are logged:
• Data of the whole system:
o Action: Extend or Retract
o Position: mm or Inches
o Pressure: Bar or Psi
o Load: kN or Short Tonne or Kips
o Time off day
o Actual Height
o Number off barrels inside
• Data of the individual units:
o Alias off the Unit
o Stroke 1
o Stroke 2
o Stroke 3
o Stroke 4
o Unit Stroke
o Load 1
o Load 2
o Load 3
o Load 4
o Expected Load
o Unit Total Load
The logging file looks like:
mm,Bar,kN,Left back,-310,-310,-310,-310,-310,-316,-316,-316,-316,5000,-
1263,13:23:23,1300,0,
Right back,-310,-310,-311,-309,-310,-316,-316,-316,-316,2500,-1263,13:23:23,1300,0,
Unit3,-280,-280,-280,-280,-280,-316,-316,-316,-316,2500,-1263,13:23:23,1300,0,
Unit4,-173,-173,-173,-173,-173,-316,-316,-316,-316,2500,-1263,13:23:23,1300,0,
Left front,-310,-310,-310,-310,-310,-316,-316,-316,-316,2500,-1263,13:23:23,1300,0,
,,,,,,,,,,,,13:23:23,1300,0,
,,,,,,,,,,,,13:23:23,1300,0,
Unit8,-173,-173,-173,-173,-173,-316,-316,-316,-316,2500,-1263,13:23:23,1300,0,
,mm,Bar,kN,Left back,-310,-310,-310,-310,-310,-316,-316,-316,-316,5000,-
1263,13:23:43,1300,0,
Right back,-310,-310,-311,-309,-310,-316,-316,-316,-316,2500,-1263,13:23:43,1300,0,
Unit3,-280,-280,-280,-280,-280,-316,-316,-316,-316,2500,-1263,13:23:43,1300,0,
,,,,,,,,,,,,13:23:43,1300,0,
Left front,-310,-310,-310,-310,-310,-316,-316,-316,-316,2500,-1263,13:23:43,1300,0,
,,,,,,,,,,,,13:23:43,1300,0,
,,,,,,,,,,,,13:23:43,1300,0,
Unit8,-173,-173,-173,-173,-173,-316,-316,-316,-316,2500,-1263,13:23:43,1300,0,
,mm,Bar,kN,Left back,-310,-310,-310,-310,-310,-316,-316,-316,-316,5000,-
1263,13:24:03,1300,0,
Right back,-310,-310,-311,-309,-310,-316,-316,-316,-316,2500,-1263,13:24:03,1300,0,
Unit3,-280,-280,-280,-280,-280,-316,-316,-316,-316,2500,-1263,13:24:03,1300,0,
For evaluation purposes, you may convert the contents of the file into excel format.
