Show diagnostic data
Instruction manual Ensite Pro Configuration Tool Page 71
Press the ‘Reset Diagn. Counters’-button to .....
Press the ‘Update’-button to fetch the current values from the selected
CIU Prime/Plus and fill in the ‘Value’-column.
Clear Configuration
The clear configuration procedure should only be done when a an
existing database must be replaced by a new one. This procedure
should not be done in case of modifying an existing database.
Click on the R/W button in the “Diagnostic window”. Enter 7502 in the
Entity/name field and hex 30 in the value field and press Write.
Within a few seconds the CIU will be reset. The CIU Prime will
indicate this by simultaneous flashing of the receive and transmit
Led’s of the installed IP modules.
On the CIU Plus a window will pop up with the message
“Letterbox empty caused by reset of CIU”
To be sure that the CIU has completed the previous command,
read
the CIU name (Prime entity 502 and Plus entity 602)
The name should be default (“DefPrime” for the CIU prime and
“DefPlus” for CIU Plus).
Clear Novram
The clear Novram procedure should only be done when a an existing
database must be replaced by a new one. This procedure should not
be done in case of modifying an existing database.
Click on the R/W button in the “Diagnostic window”. Enter 7507 in the
Entity/name field and press Write. Within a few seconds the CIU will
be reset. The CIU Prime will indicate this by simultaneous flashing of
the receive and transmit Led’s of the installed IP modules.
On the CIU Plus a window will pop up with the message “Letterbox
empty caused by reset of CIU”
To be sure that the CIU has completed the previous command,
read
the CIU name ( Prime entity 502 and Plus entity 602) The name
should be default (“0” for the CIU prime and “CIUPlus” for CIU Plus).
