Entrust Sigma DS3 User Manual

4 About the Printer
Printer Components
Use the following sections to become familiar with the printer.
Printer Left Side
Wi-Fi USB Port The Wi-Fi port allows you to insert the optional Wi-Fi Dongle in
the printer.
Cable Lock Receptacle The receptacle allows you to insert the security plate before
attaching the optional cable lock.
Power Connection The power connection provides a plug-in connector for the
printer power supply.
USB Connection The USB connection allows you to connect the printer directly
to a computer.
Data Port The data port allows you to connect the printer to another
component, such as a laminator.
Ethernet Connection The network connection allows you to connect the printer to an
Ethernet network.
Wi-Fi USB Port
USB Connection
Power
Connection
Cable Lock
Receptacle
Data Port
Ethernet
Connection

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
