Entrust Sigma DS3 User Manual

10 About the Printer
Print Ribbons
Depending on the printer model, the print ribbon is available as a replaceable roll that is loaded
on the ribbon cartridge, or as part of a prefilled print ribbon cassette.
Ribbon Cartridge
The ribbon cartridge holds a roll of ribbon that you can replace when it runs out. The cartridge
also holds a cleaning roller that is replaced with each ribbon change. Refer to “Load the Print
Ribbon Cartridge” on page 29.
Ribbon Cartridge The ribbon cartridge holds a replaceable print ribbon.
Print Ribbon The print ribbon is used to apply images to the card.
Cleaning Roller The replaceable cleaning roller removes dust and other particles
from the cards as they move into the printer.
Cleaning Roller
Retainer
Pull up on the retainer to load the cleaning roller on the print ribbon
cartridge. Release the retainer to secure the roller in position.
Ribbon Cartridge
Handle
Use the handle to remove the ribbon cartridge from the printer.
Cleaning
Roller
Ribbon Cartridge
Handle
Print Ribbon
Ribbon Cartridge
Cleaning Roller
Retainer

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
