Entrust Sigma DS3 User Manual

18 Using the Printer
When you use the arrow keys to view the printer IP address, the LCD panel also displays a QR
code. Scan the QR code from a mobile device to start the Printer Dashboard to see additional
printer information and work with the printer.
LCD Panel Icons
The LCD panel displays icons to indicate the status of the printer.
To successfully scan the QR code on the IP address panel requires a camera with a
resolution of 5 megapixels or higher.
Icon Description
WiFi is enabled and connected.
WiFi Dongle is installed, but not connected.
Cloud connection is active.
Cloud is enabled but not connected.
There is an issue with the card supply. Additional information displays on
line 3 of the LCD panel. The LED light bar blinks.
Refer to “Printer Messages” on page 65 for a list of LCD messages that
correspond to card issues.
The printer is unlocked. The LED light bar blinks.
There is an issue with the print ribbon. Additional information displays on
line 3 of the LCD panel. The LED light bar blinks.
Refer to “Printer Messages” on page 65 for a list of LCD messages that
correspond to print ribbon issues.
OpenCard is enabled.

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
