Entrust Sigma DS3 User Manual

Sigma DS1, DS2, DS3 Card Printer User’s Guide 25
5. Record the address.
6. Press the down arrow until Exit displays on line 3.
7. Press E
NTER. Then, press the USER button to return the printer to Ready.
Print a Test Card
The printer includes a one-sided test card that prints without using a driver or other source of
card data. Use it to verify that the printer is printing correctly. Make sure that cards are in the
input hopper and all supplies are loaded before you begin. Refer to “Load and Replace Supplies”
on page 26 for complete information. You can print more advanced test cards from the Printer
Dashboard.
1. Begin with the printer in Ready status. Press the U
SER
button.
2. Suspended displays on line 1 of the LCD panel. Press E
NTER
to enter the menu system.
3. Maintenance displays on line 3. Press E
NTER to enter the
Maintenance menu.
4. Cleaning Card displays on line 3. Press the down arrow to
display Test Card on line 3.
5. Press E
NTER.
6. With Test Card displayed on line 2, press E
NTER to display
Start on line 3.
7. Press E
NTER to print the test card.
After the card prints, the printer returns to Ready.
A stateless (SLAAC) configuration (if enabled) can have multiple values depending
on the router setup. The LCD displays up to four SLAAC addresses. An additional
digit in line 1 indicates which address is being displayed.

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
