Sigma DS1, DS2, DS3 Card Printer User’s Guide 31
3. Extend the cassette to its fully open position.
Pull out the front of the cassette until it clicks.
4. Remove the protective wrapper from the cleaning
roller.
5. Install the cassette in the printer.
a. Hold the ribbon cassette by the handle and lower it
into the printer with the handle toward the front of
the printer.
b. Position the ribbon cassette in the guides.
6. Close the printer cover. Press down on the ridges on the
front of the cover to make sure that is latches completely.
Use the Printer Dashboard
The Printer Dashboard is a web-based printer management tool. You can access the Printer
Dashboard using one of the following methods:
 Enter the printer’s IP address in a browser window. For example, https://12.3.45.678.
 Scan the QR code on the printer front panel with a mobile device when the printer IP address
is displayed (refer to “Down Arrow, Up Arrow, and Enter Key” on page 17 for more
information).
 Double-click the Printer Dashboard icon on the computer desktop. The Printer Dashboard
icon is placed on the desktop when you use the QuickInstaller or install the XPS Card Printer
Driver (refer to the XPS Card Printer Driver User’s Guide for more information).
The system administrator sets up accounts for users who can access the Printer Dashboard.
Protective
Wrapper

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
