Entrust Sigma DS3 User Manual

12 About the Printer
Printer Back
Some printer models can have an additional module, such as a tactile impression module (TIM),
mounted to the back of the printer.
Printer Rear Exit Slot The rear exit slot allows the card to move into the tactile
impression module from the printer.
Rear Module Data
Connection Port
The electrical connection for the impresser to connect to the
printer.
Rear Module
Connection Slots
The connection slots allow the impresser to connect to the printer.
Refer to the Tactile Impression Module Upgrade Installation
Instructions for complete information about how to install the
impresser.
Rear Module
Connection Slots
Printer Rear
Exit Slot
Rear Module Data
Connection Port
Rear Module
Connection Slot

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
