Sigma DS1, DS2, DS3 Card Printer User’s Guide 9
Inside the Printer
Printhead The printhead transfer the card images to the card using the print
ribbon.
Manual Advance
Knob
The knob moves a card in the track to clear a card jam.
Ribbon Cartridge
Handle
Lift up the handle on the ribbon cartridge or cassette to remove it
from the printer.
Ribbon Cartridge or
Cassette
The ribbon cartridge or cassette holds the print ribbon and cleaning
roller.
Ribbon Cartridge
Handle
Manual Advance
Knob
Printhead
Ribbon Cartridge
or Cassette

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
