Epson Aculaser C9200N User Manual

EPSON AcuLaser C9200N Revision D
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 162
Confidential
4.3 Main Unit Disassembly/Reassembly
4.3.1 Group 1
CONTENT
Parts/Units to be Disassembled Guide
Front Door
Transfer Belt Unit
Photoconductor Unit
Fusing Unit
Waste Toner Collector + Exhaust Filter
A
B
C
D
E
Front Cover
A
Photoconductor Unit
C
Waste Toner Collector
EE
Exhaust Filter
E
Fusing Unit
D
Transfer Belt Unit
B
