2.2.6 Charge Corona section
2.2.6.1 Composition
Figure 2-16. Composition
4038T2C027AA
4039T2C108AA
Comb
Electrode
Grid Mesh
Grid Mesh
Cleaning Blade
Comb Electrode/Y, M, C, K
